Caractéristiques

Product Type: medical

Condition: New

Machine Type: Granulator

Output (kg/h): 15

Video outgoing-inspection: Provided

Machinery Test Report: Provided

Marketing Type: Hot Product 2021

Warranty of core components: 1 Year

Core Components: PLC, Pump, Other

Voltage: 380V

Dimension(L*W*H): refer to installation drawing

Weight (KG): 1200

Power (kW): 11

Warranty: 1 Year

Key Selling Points: Sustainable

Applicable Industries: Manufacturing Plant, Pharmaceutical company

Showroom Location: Canada, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Thailand, Bangladesh, Ukraine, Uzbekistan

Product Name: Fluid Bed Drying Granulator Fluid Bed Dryer Equipment

Material yield rate (%): â‰¥99

Scope of application for liquid(g/cm3): <1.3

Power of supply liquid motor (Kw): 0.37

Defects Liability Period: 12 month after installation or 18 months since BL date

Driven Type: Electric

After-sales Service Provided 1: Field installation, commissioning and training

After-sales Service Provided 2: Video technical support

After-sales Service Provided 3: Online support

Informations de base

Conditions de paiement et expédition

Packaging Details: Mixer Granulator Pharmaceutical Fluid Bed Drying Granulator Fluid Bed Dryer Equipment Packaging: wooden case

Supply Ability: 10 Set/Sets per Month High quality GMP designed pharmaceutical fluid bed granulator dr

Description de produit

Products Description

Introduction

The machine is mainly used for the operations of mixing, granulating, drying and coating of granule “Top Spraying”, etc of powder material in pharmaceutical industry, foodstuff industry, chemical industry, etc. Such as granule of tablet, granule for quick resolving drinking, condiment.
Mixing-granulating-drying in one-step.
Adopting double chamber filtering bags system, removing dust completely.
Adopting multi-fluid nozzle, it guarantees that the formed granule is uniform and the content of powder is very low.
Can choose 2 bar explosion-proof design.
Designed, manufactured and laid out by GMP.

Function feature and the principle of action

This machine is suitable for drying for powder and granules.

The principle of action is based on: Put the raw material into the fluid bed. The cold air is drawn into the fluid bed through the pre filters and passes through the heating chamber behind the main machine, heated to the desired temperature by the heater. The material is fluidized in the fluid bed regularly. The evaporating moisture is drawn out by the fan.

Technical Data

Capacity (Kg /batch)	5	15	30	60	120	200	300	500	800-1000
Scope of application for liquid(g/cm3)	<1.3								By client
Material yield rate (%)	≥99
Qualified rate of end products (%)	≥85
Container volume (L)	22	45	100	220	420	670	1000	1500
Diameter r(mm)	500	550	700	1000	1200	1400	1600	1800
Power of fan (Kw)	3	5.5	7.5	11	18.5	22	30	45
Power of supply liquid motor (Kw)	0.37
Pressure of steam (Mpa)	0.4-0.6
Consumption of steam (Kg/h)	18	35	60	120	140	180	310	400
Pressure of compressed air (Mpa)	0.4-0.6
Working temperature (℃)	Normal temperature -120℃ could adjust
Overall dimension of machine (L×W×H)	refer to installation drawing or customer’s room

Material	Stainless Steel
Customized	Accept
Service	OEM and OEM
Package	Standard wooden packing for sea shipping

Any questions,

Please feel free to contact us!
